E25 200:6 Transformer

The EE25 200:6 is a compact, high-frequency, single-phase transformer designed for switching power supplies, particularly in IGBT inverter welding machines (e.g., ZX7-200). It features a 200:6 turn ratio, high efficiency (>95%), and operates between 10kHz-1MHz. The transformer is used for voltage reduction and isolation, with 3-4 windings.
